Product Overview

Complete OLED display development solutions for GUI demonstration applications. Choose from three display technologies and sizes based on your specific application needs—from display-only modules to complete development kits with driver boards.

Key Features:
  • Three display options: AMOLED (3.92", 7.0") and PMOLED (4.05")
  • AMOLED displays include integrated capacitive touch
  • PMOLED option for simple, cost-effective grayscale applications
  • Standard interfaces: MIPI for AMOLED, Parallel/SPI for PMOLED
  • Complete technical documentation and sample code
  • Full technical support during evaluation
  • Clear path to production volumes

Available Display Options

3.92 inch AMOLED display

Kit A: 3.92" AMOLED

Compact, Full Color with Touch

1080 × 1240 pixels

7.0 inch AMOLED display

Kit B: 7.0" AMOLED

Large Format with Touch

1080 × 1920 pixels (Full HD)

4.05 inch PMOLED display

Kit C: 4.05" PMOLED

Cost-Effective Grayscale

256 × 64 pixels

Technical Specifications

Kit A: 3.92" AMOLED Display

Model: Visionox G1392FH101GG-003

Size 3.92" diagonal
Type AMOLED (Active Matrix TFT)
Resolution 1080 × 1240 pixels
Active Area 65.448mm × 75.144mm
Touch Capacitive multi-touch
Interface MIPI DSI + I2C touch
Brightness 700+ cd/m²

Kit B: 7.0" AMOLED Display

Model: Visionox G1700FH101GG-003

Size 7.0" diagonal (iPad Mini size)
Type AMOLED (Active Matrix TFT)
Resolution 1080 × 1920 pixels (Full HD)
Active Area 87.1344mm × 154.9056mm
PPI 315 (High Definition)
Touch Capacitive multi-touch
Interface MIPI DSI + I2C touch
Brightness 800+ cd/m²
Technology LTPS

Kit C: 4.05" PMOLED Display

Model: VGM256064A7W01 (Product Code: M03170)

Size 4.05" diagonal
Type PMOLED (Passive Matrix)
Resolution 256 × 64 pixels
Active Area 99.81mm × 24.93mm (wide format)
Color White grayscale (16 levels)
Touch None (display only)
Interface 8-bit 8080/6800, 4-wire SPI, 3-wire SPI
Driver IC SSD1322UR1
Brightness 75 cd/m² (typical)
Operating Temp -40°C to +70°C

Three Flexible Options

Option 1: Display Module Only ⭐ RECOMMENDED

Best Value for Most Developers

What's Included:

  • OLED display module (AMOLED for A/B, PMOLED for C)
  • Integrated capacitive touch (Kit A & B only)
  • Technical datasheet
  • Sample code and driver libraries
  • Interface documentation
  • Email technical support

You Provide: MCU/driver board (MIPI for Kit A/B, Parallel/SPI for Kit C), Programming environment

Best for: Teams ready to integrate displays into their development environment

Option 2: Basic Development Kit

Complete Testing Solution with Driver Board

What's Included:

  • OLED display module (with integrated touch for A/B)
  • Simple driver board - Ready to program
  • All connection cables (FPC, power, USB)
  • Complete technical datasheet
  • Sample code and driver libraries
  • Interface documentation
  • Quick start guide
  • Email technical support

You Provide: PC with USB port, Programming software (free downloads provided)

Best for: Teams new to OLED displays who need a working driver board to get started quickly

Option 3: Complete Development Kit

Professional Turnkey Solution

What's Included:

  • Everything in Basic Kit, PLUS:
  • Professional development board (Kit A/B: professional grade; Kit C: simpler board)
  • GUI builder software (Kit A/B)
  • Advanced debugging capabilities
  • Priority support (same-day response)
  • Video tutorials and training
  • Pre-configured examples
  • Complete development environment

Best for: Teams new to display development who want a professional, turnkey solution (Kit A/B recommended for full GUI development)

Comparison Table

Feature Display Only ⭐ Basic Kit Complete Kit
AMOLED Display ✓ ✓ ✓
Integrated Touch ✓ ✓ ✓
Datasheet & Docs ✓ ✓ ✓
Sample Code ✓ ✓ ✓
Driver Board ✗ You provide ✓ Simple ✓ Professional
Cables Included ✗ ✓ ✓
GUI Builder ✗ ✗ ✓
Priority Support ✗ ✗ ✓
Best For Most developers New to MIPI Turnkey solution

Technology Comparison: Choosing the Right Display

Factor PMOLED (Kit C) AMOLED (Kit A & B)
Best For Simple status displays, indicators Full GUI, interactive applications
Resolution 256×64 pixels 1080×1240 to 1920×1080 ✓
Color Grayscale (16 levels) Full RGB color ✓
Touch Not included Integrated capacitive ✓
Interface Simple Parallel/SPI ✓ MIPI DSI
Brightness 75 cd/m² 700-800 cd/m² ✓
Power Lower consumption ✓ Higher consumption
Integration Easier (SPI) ✓ Requires MIPI interface
When to Choose PMOLED (Kit C):
  • Simple text or icon displays (status bars, indicators, basic HMI)
  • Cost-sensitive applications
  • No touch interaction needed
  • Easy MCU integration with standard SPI/parallel interface
When to Choose AMOLED (Kit A or B):
  • Full-color GUI applications
  • Touch-enabled interactive interfaces
  • High-resolution graphics and images
  • Customer-facing demo units requiring premium quality

Production Volume Pricing

Once you've completed evaluation and are ready for production volumes, we offer competitive pricing on display modules:

Volume Pricing Available:

  • AMOLED prices include integrated touch panel
  • PMOLED prices are display-only (no touch)
  • Driver boards available separately (reusable for multiple displays)
  • Includes testing, QC, packaging
  • Lead time: 6-8 weeks for production volumes
  • Payment terms: 50% deposit, 50% before shipment
  • Minimum order quantity: 100 pieces
  • Contact us for volume pricing at 100, 1,000, and 10,000+ piece quantities

Ready to Get Started?

Contact us to discuss your display requirements, request samples, pricing information, or place an order.
Our team is ready to help you find the perfect display solution for your application.

Contact Us Today

What You Get With Every Kit

📋 Documentation

  • Complete technical datasheets
  • Interface specifications
  • Integration guides
  • Sample code libraries

🛠️ Technical Support

  • Email support included
  • Integration assistance
  • Troubleshooting help
  • Priority support available

🚀 Path to Production

  • Volume pricing available
  • Customization options
  • Quality assurance
  • Reliable supply chain
